Product Description

The Footprint03 is a tri-amplified 3-way studio monitor coming from Barefoot Sound’s highly acclaimed Footprint series. Maintaining the exceptional audio quality and design characteristics of its predecessors, the Footprint01 and Footprint02, it offers a more compact design and an affordable price.

Departing from the traditional sealed cabinet design, the Footprint03 embraces a fast transient ported speaker design, achieving remarkable low-end extension while upholding Barefoot’s renowned standards in cabinet construction. The cabinet’s Footprint Gray polyester coating, stress assembly techniques, and substantial weight contribute to stability and damping, combatting potential vibrations for an unparalleled listening experience.

Delving into the heart of the Footprint03’s innovation, the speaker boasts a 1″ ring radiator tweeter, a 3.5″ midrange driver with an aluminum cone, and a forward-facing 6.5″ aluminum cone woofer, each meticulously designed to enhance audio fidelity. The incorporation of advanced magnet and motor systems, copper shorting rings, and an improved heat-sink system ensure minimal distortion, longer excursion capabilities, and reliable performance even during extended use. The introduction of SPOC™ (SPectrally Optimized Conversion) technology and a groundbreaking Digital Signal Processor (DSP) further elevate the audio experience, providing higher resolution, reduced latency, and optimized frequency response for audiophiles and professionals alike. Barefoot’s MEME™ Technology adds another layer of versatility, allowing seamless integration into various applications, making the Footprint03 a true powerhouse in studio monitoring in a small package.

Features & Specs:

  • Description: Tri-amplified 3-way studio monitor with MEME™ Technology
  • Controls: Input level stepped attenuator, MEME™ voice select
  • Analog Input: XLR female, Pin 1 ground, Pin 2 positive, Pin 3 negative
  • TRS Male, Tip: Positive, Ring: Negative, Sleeve: Ground
  • Input Impedance = 20k Ohms
  • Input Sensitivity (1m) = 90 dB @ -15 dBV (pass band)
  • Analog to Digital Conversion: Word Length: 28-bit (56-bit High Precision)
  • Sample Rate: 96 kHz
  • Signal/Noise ≥ 100 dB
  • Frequency Response: 45 Hz–40 kHz (+/-3 dB), 50 Hz–22 kHz (+/- 1 dB )
  • Bass Response: -3 dB @ 46 Hz
  • Q = 0.707 Slope = 18 dB/octave
  • MAX SPL: Continuous 101 dB
  • Cabinet: 10.5 liters total internal volume
  • Solid aluminum baffle plate
  • Polyurethane acoustic damping throughout
  • Crossover Frequencies: 600 / 3900 Hz (Active crossover between drivers)
  • Tweeter: 1″ ring radiator, low distortion motor, rear waveguide chamber. Amplifier: 60W
  • Midrange: 3.5″ aluminum cone, aluminum phase plug, Low distortion motor +/- 3.5 mm linear excursion Amplifier: 100W
  • Woofers: 6.5″ aluminum cone with low distortion motor +/- 9.5 mm linear excursion. Amplifier: 100W
  • High Frequency Amplifier: 60W
  • Mid Frequency Amplifier: 100W
  • Low Frequency Amplifier: 100W
  • Power: Mains Voltage Input: 85 VAC to 265 VAC universal
  • Idle Power Consumption = 12W
  • Maximum Power Consumption = 340W
  • Weight: Speaker: 17.5 lbs each (12.66 kg)
  • Dimensions HxWxD: 9″ x 13.25″ x 9.25″ (229 x 337 x 235 mm)
